Image sensor | Type |
1/2.33″ (Approx. 7.79mm) CCD |
Effective Pixel |
Approx. 12.2 Mega pixel |
Total Pixel |
Approx. 12.4 Mega pixel |
Lens | Focal Length |
Samsung 5X Lens f = 6.3 ~ 31.5mm (35mm film equivalent : 35~175 mm) |
F No. |
F3.6(W) ~ 4.8(T) |
Digital Zoom |
Still image mode : 1.0X ~ 5.0X Play mode : 1.0X ~ 12.5X (depends on image size) |
Viewfinder | Electronic Viewfinder |
N/A |
LCD Monitor |
2.7" (6.9cm) (230,000 pixel) |
Focusing | Type |
TTL auto focus (Multi AF, Center AF, Face Detection AF, Tracking AF) |
Range |
Normal : 80cm ~ infinity Macro : 5cm ~ 80cm (Wide), 50cm ~ 80cm (Tele) Auto Macro : 5cm ~ Infinity (Wide), 50cm ~ Infinity (Tele) |
Shutter | Type |
N/A |
Speed |
Smart Auto : 1/8 ~ 1/1,000 sec. Program : 1 ~ 1/1,000 sec. (Night Scene : 8 ~ 1/1,000 sec.) |
Exposure | Control |
Program AE |
Metering |
Multi, Spot, Center-weighted, Face Detection AE |
Compensation |
±2EV (1/3EV steps) |
ISO Equivalent |
Auto, 80, 100, 200, 400, 800, 1600, 3200 |
Flash | Modes |
Auto, Auto & Red-eye reduction, Fill-in flash, Slow sync, Flash off, Red-eye fix |
Range |
Wide : 0.2m ~ 3.0m, Tele : 0.5m ~ 2.0m (ISO AUTO) |
Recharging Time |
Approx. 4 sec. |
Effect | Sharpness |
Soft+, Soft, Normal, Vivid, Vivid+ |
White Balance |
Auto, Daylight, Cloudy, Fluorescent_H, Fluorescent_L, Tungsten, Custom |
Shooting | Still Image |
▶Mode : Smart Auto, P, Scene *Smart Auto : Portrait, Night Portrait, Night, Backlight Portrait, Backlight, Landscape, White, Macro, Macro Portrait, Macro Text, Macro Color, Tripod, Action, Natural Green, Blue Sky, Sunset *Scene : Aqua, Beautyshot, Night, Frame Guide, Portrait, Children, Landscape, Close-up, Text, Sunset, Dawn, Back light, Firework, Beach&Snow ▶Continuous: Single, Continuous, AEB, Motion Capture ▶Self-timer : 2 sec., 10 sec., Double * Smart Scene Detection Selectable |
Movie Clip |
Scene Recognition : Landscape, Natural Green, Blue Sky, Sunset With Audio or without Audio (Max Recording time (HQ Recording) : 20min) Size : High Quality-1280x720(30fps & 15fps) Standard Quality-640x480(30fps & 15fps) , 320x240 (60fps & 30fps & 15fps) (5X Optical Zoom with sound recording) * Due to the noise while optical zooming, user can select to record sound or not. |
Storage | Media |
Internal Memory : About 20MB External Memory(Optional) : SD (up to 2GB guaranteed) SDHC (up to32GB guaranteed) * Internal memory capacity is subject to change without prior notice. |
File Format |
Still Image : JPEG (DCF), EXIF 2.21, DPOF 1.1, PictBridge 1.0 Movie Clip :MP4 (H.264(MPEG4.AVC)) Audio : WAV |
Image Size |
12MP: 4000 x 3000 pixels 10MP: 3984 x 2656 pixels, 9MW : 3840 X 2160 pixels, 8M: 3264 x 2448 pixels 5M: 2560 x 1920 pixels, 3M: 2048 x 1536 pixels 2MW: 1920 x 1080 pixels, 1M: 1024 x 768 pixels |
Capacity (256MB) |
N/A |
Image Play | Type |
N/A |
Editing |
Single image, Thumbnails, Advanced Slide show, Movie Clip, Smart Album * Slide show : Slide show with Effect & Music |
Interface | Digital Output Connector |
USB 2.0 |
Audio |
Microphone : Stereo Internal Speaker : Mono |
Video output |
NTSC, PAL (user selectable) |
DC power input connector |
4.2V |
Power Supply | Power Source |
Rechargeable battery : BP-70A Adaptor : SAC-48, CB20U05A Connector Type : 20pin * Included battery may vary depending on sales region. |
Physical Specification | Dimensions (WxHxD) |
93.8 x 61 x 18.5mm (Excluding protrusions) |
Weight |
121 g (without battery and card) |
Operating Temperature |
0 ~ 40°C |
Operating Humidity |
5 ~ 85% |
Software | Application |
Intelli-studio, Adobe Reader |
MP3 Specification | Audio | Frequency |
N/A |
Earphone Port |
N/A |
Output |
N/A |
Noise Ratio |
N/A |
Sound Effect |
N/A |
Play Mode |
N/A |
File | File Format |
N/A |
Bit Rate |
N/A |
PMP Specification | PMP Decoder | Movie |
N/A |
Audio |
N/A |
Subtitle |
N/A |
TEXT Specification | File |
N/A |
File Format | Window |
N/A |
Mac |
N/A |
Function |
N/A |
Language |
N/A |
Voice Recording |
|
Voice Recording (max. 10 hours) Voice Memo in Still Image (max. 10 sec.) |
Date Imprinting |
|
Date&Time, Date, Off (user selectable) |
